MCDL Stainless Steel Vertical Multi Stage Pump Water Supply Equipment

MCDL stainless steel vertical multi stage pump water supply equipment

Product Details

MCDL stainless steel vertical multi stage pump water supply equipment

Product description

MCDL, CDLF type of stainless steel sheet metal stamping,forming vertical multistage centrifugal pump , with the use of health clean, high efficiency,low noise, resistance to mildly corrosive and compact structure,beautiful appearance, small size, light weight, The use of easy maintenance, and reliable sealing performance.

Features

High efficiency low noise
Resistance to mildly corrosive
Use of easy maintenance
Reliable sealing performance

CDL1225-_03 CDL1225-_06 CDL1225-_04

Performance table

MCDL8/MCDLF8 Parameters
Model	Power (kw)	Flow(m3/h)	5	6	7	8	9	10	11
8-20	1.1	Head (m)	20	19	18	17	17	16	14
8-30	1.5		30	28	27	26	26	24	21
8-40	2.2		40	38	37	36	34	32	28
8-50	2.2		50	49	47	45	43	40	35
8-60	3		60	59	57	54	51	48	42
8-70	3		70	68	62	61	60	56	49
8-80	4		80	78	72	70	68	64	56
8-90	4		90	87	84	81	77	72	63
8-100	4		100	96	95	90	85	80	70
8-110	5.5		110	105	105	99	94	88	77
8-120	5.5		120	115	114	108	102	96	84
8-130	5.5		130	124	123	117	111	104	91
8-140	5.5		140	133	132	126	119	112	98
8-150	7.5		150	142	141	135	128	120	105
8-160	7.5		160	151	150	144	136	128	112
8-170	7.5		170	160	159	153	145	136	119
8-180	7.5		180	170	170	162	153	144	126
8-190	7.5		190	179	180	171	162	152	133
8-200	11		200	188	190	180	170	160	140
8-210	11		210	197	199	189	179	168	147
8-220	11		220	206	210	198	187	176	154
MCDL32/MCDLF32 Parameters
Model	Power (kw)	Flow(m3/h)	16	20	24	28	32	36	40
32-100-2	18.5	Head (m)	175	166	157	146	131	115	91
32-100	18.5		182	173	164	152	138	122	98
32-110-2	22		193	184	173	164	146	128	102
32-110	22		200	191	180	168	153	135	109
32-120-2	22		211	201	189	178	160	140	113
32-120	22		218	208	196	184	167	147	120
32-130-2	30		230	218	206	193	174	153	124
32-130	30		237	225	213	200	181	160	131
32-140-2	30		247	235	222	210	189	165	135
32-140	30		255	242	229	216	196	172	142
