Centrifugal Monoblock Pump
Product Details
Centrifugal monoblock pump is used to transport clean water and other liquids with similar physical properties to clean water. The medium temperature is below 80℃. It is suitable for industrial and urban water supply and drainage, high-rise building pressurized water supply, garden sprinkler irrigation, fire fighting pressurization, long-distance water delivery, heating, bathroom hot and cold water circulation pressurization and equipment matching, etc.
Centrifugal monoblock pump main performance range
Flow rate: 3-250m³/h
Head: 3~160m
Pump inlet and outlet diameter: 1~6inch
Working temperature: 1°C ~ 40°C
The maximum working pressure of the pump system is ≤1.6MP
Pump model description
Example: ISW 80-160(I) A(B)
80: Inlet/outlet diameter (mm)
160: Impeller nominal outer diameter (mm)
(I): Incremental capacity
A: Impeller passes the first cut
(B): Impeller passes the second cut
Features of centrifugal monoblock pump
1. Compact structure. This series of pumps is a horizontal structure with integrated machine and pump, beautiful appearance, small footprint, and 30% less floor space than ordinary horizontal pumps.
2. Smooth operation, low noise, and high component concentricity. The motor and pump are directly connected, which simplifies the intermediate structure and enhances the smoothness of operation. The impeller has good dynamic and static balance, small vibration during operation, and improves the use environment.
3. No leakage. The shaft seal adopts corrosion-resistant hard alloy mechanical seal, which solves the serious leakage problem of centrifugal pump packing and ensures a clean and tidy operating site.
4. Easy maintenance. This series of horizontal pumps has a rear-opening structure and can be repaired without disassembling the pipeline.
5. From the inlet direction of this series of horizontal pumps, the outlet of the pump can be installed in any of three directions: horizontal left, vertical upward, and horizontal right.
