Horizontal Large Flow Double Suction Split Case Water Pump With Control Cabinet
Product Details
Horizontal large flow double suction split case water pump with control cabinet
Introduction:
The S series pumps are single stage, double suction; horizontal split case pumps designed for high volume water transfer in a wide range of applications. Centurion pumps are available in 43 sizes ranging from 80mm to 400mm discharge and capable of capacities up to 4000 cubic meters per hour and heads up to 160 meters. Centurion pumps offer ease of maintenance with simple assembly/disassembly (no requirement for special tools). All major wear components and replaceable parts are easily accessible and can be changed out with minimal effort and downtime, without removing the suction and discharge piping.
Application:
Performance Curve:
Pump Performance:
| Pump Model | Capacity (m3/h) | Head(m) | Motor Power (kw) | Speed (rpm) | NPSH (m) |
| 150S-50 | 160 | 50 | 37 | 2950 | 3.9 |
| 150S-78 | 160 | 78 | 55 | 2950 | 3.7 |
| 200S-42 | 280 | 42 | 45 | 2950 | 6 |
| 200S-95 | 280 | 95 | 132 | 2950 | 5.3 |
| 250S-14 | 485 | 14 | 30 | 1450 | 3.8 |
| 250S-65 | 485 | 65 | 132 | 1450 | 3.1 |
| 300S-90 | 790 | 90 | 315 | 1450 | 4.2 |
| 350S-125 | 1260 | 125 | 710 | 1450 | 5.4 |
| 400S-90 | 1620 | 90 | 560 | 1450 | 6.2 |
| 500S-59 | 2020 | 59 | 450 | 970 | 4.5 |
| 600S-75 | 3170 | 75 | 900 | 970 | 6 |
| 800S-76 | 5500 | 76 | 1600 | 730 | 6 |
| 800S-76 | 4400 | 49 | 800 | 585 | 4.2 |
Construction Material:
S type pump could supplied in Cast iron, Ductile iron, Stainless steel material.
| Part Description | Cast Iron | Ductile Iron | Stainless Steel |
| Casing | AS1830/T260 | AS1830/300-17 | AS2074/H6B |
| Shaft | AS2837/420 | ||
| Impeller | AS2074/H6B | AS1830/300-17 | AS2074/H6B |
| Shaft Sleeves | AS2074/H6B | ||
| Lantern Ring | AS1565/ALLOY 836B | AS1830/T260 | AS2074/H6B |
| Gland | AS1830/T260 | AS2074/H6B | |
| Wearing Ring | AS2074/H6B | ||
Company Introduction:
We have the key to deal with the pump! We'd like to be your pump technical support to win the order together!
