High Head Mining Slurry Pump

The DEPUMP® slurry pump is the world's standard for the most difficult mill duties. A wide variety of impellers and shaft seals provide a prefect fit for a wide range applications. The DEPUMP® slurry pump provides excellent wear life while maintaining.

Horizontal High Pressure High Chrome Wet End Centrifugal slurry pump apply to Mining Mud Slurry Drainge Water Pump

Features

1 Bearing assembly:large diameter shaft with short overhang contributes to long bearing life;

2 Liners:Easily replaceable liners are bolted, not glued to the casing for positive maintenance;

3 Casing:Casing halves of cast or ductile iron provide high operating pressure capabilities;

4 Impeller:Front and rear shrouds have pump out vanes that reduce recirculation and seal contamination;

5 Throatbush:Wear is reduced and maintenance simplified by the use of tapered.

Structure Of Pump

Horizontal High Pressure High Chrome Wet End Centrifugal slurry pump apply to Mining Mud Slurry Drainge Water Pump

Pump parts

Horizontal High Pressure High Chrome Wet End Centrifugal slurry pump apply to Mining Mud Slurry Drainge Water Pump

Performance Curve

Horizontal High Pressure High Chrome Wet End Centrifugal slurry pump apply to Mining Mud Slurry Drainge Water Pump

Performance Table

Clear water performance of DP-AH
Type	Max. power	Capacity		Head	Speed	Max. Eff	NPSH	IMPELLER		Max. particle size	Weight (KG)
	Max. power	Capacity		Head	Speed	Max. Eff	NPSH	Quantity of vanes	Diameter (mm)	Max. particle size
	kw	(m³/h)	(l/s)	(m)	(r/min)	%	(m)	Quantity of vanes	Diameter (mm)	mm
DAH1.5/1	15	12-28	3.5-8	6-65	1200-3800	40	2-4	5	150	14	90
DAH4/3	30	86-198	24-55	9-52	1000-2200	71	4-6	5	245	28	260
DAH6/4	60	162-360	45-100	12-56	800-1500	68	5-8	5	365	44	625
DAH6/4	120	162-360	45-100	12-56	800-1500	68	5-8	5	365	44	728
