Horizontal Centrifugal Cutter Slurry Pump
Product Details
Horizontal centrifugal cutter slurry pump
The Depump® slurry pump is the world’s standard for the most difficult mill duties. A wide variety of
impellers and shaft seals provide a perfect fit for a wide range of applications. The Depump® slurry
pump provides excellent wear life while maintaining efficiency during the wear cycle providing the
best total operating cost.
Features
· Bearing assembly- large diameter shaft with short overhang contributes to long bearing life.
· Liners – easily replaceable liners are bolted, not glued to the casing for positive maintenance.
· Casing – Casing halves of cast or ductile iron provide high operating pressure capabilities.
· Impeller – front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.
· Throatbush – wear is reduced and maintenance simplified by the use of tapered.
Performance Of DP-MAH | |||||
Type | Max. | Capacity | Head | Impeller | Max. |
Quantity | |||||
kw | (m³/h) | (m) | (mm) | ||
1.5x1B-MAH | 15 | 3.6-21.6 | 6-65 | 5 | 14 |
1.5x2B-MAH | 15 | 7.2-48.6 | 5-62 | 5 | 19 |
2x3C-MAH | 30 | 21.6-88.56 | 15-40 | 5 | 21 |
4x3C-MAH | 30 | 28.8-158.4 | 7-53 | 5 | 28 |
6x4D-MAH | 60 | 72-331.2 | 11-64 | 5 | 44 |
8x6E-MAH | 120 | 126-720 | 6-62 | 5 | 63 |
10x8ST-MAH | 560 | 216-1051.2 | 9-64 | 5 | 76 |
12x10ST-MAH | 560 | 316.8-1620 | 10-66 | 5 | 86 |
14x12ST-MAH | 560 | 504-2455.2 | 10-75 | 5 | 90 |
