Horizontal Multistage Centrifugal Boiler Feed Water Pump

Horizontal Multistage Centrifugal Boiler Feed Water Pump

High Pressure Multistage Pumps ,Boiler Feed Water Pump

Product Details

Horizontal Multistage Centrifugal Boiler Feed Water Pump

24cd2fad17f95fca95149abbe5e76d4 拷贝

24cd2fad17f95fca95149abbe5e76d4 拷贝

e80eff9dd6cdb7f4b84b65f55403298 拷贝

DG45-80-8 (1) 拷贝

DG45-80-8 (4) 拷贝

D Pump Performance Chart:

Pumps Drawing:

D PUMP STRUCTURE:

Sectional Arrangement

1	Suction Casing
2	Diffuser
3	Stage Casing
4	Delivery Casing
5	Impeller of First-stage
6	Impeller
7	Balance Disc
8	Balance Ring
9	Stuffing Box Housing
10	Packing
11	Balance Sleeve
12	Packing Gland
13	O-ring
14	Bearing
15	Wearing Ring of First-stage
16	Wearing Ring
17	Diffuser Bush
18	Shaft
19	Shaft Sleeve
20	Balance Water Piping
21	Water Seal Piping

Application:

* Long distance water transferring

* Boiling water feeding and transferring

* Water system boosting

* Agricultural irrigation

* Mining water supply

* Fire fighting

* Offshore projects

PUMPS DATA SHEET:

Model	Capacity (m3/h)	Head(m)	Speed (rpm)	Motor Power (kw)	Impeller Dia (mm)
D/DG6-50*6	6.3	300	2950	30	198
D/DG6-80*3	6.3	240	2950	18.5	235
D/DG12-25*4	12.5	100	2950	11	146
D/DG12-50*6	12.5	300	2950	30	273
D/DG12-80*4	12.5	320	2950	45	235
D/DG25-30*3	25	90	2950	15	160
D/DG25-50*5	25	250	2950	37	196
D/DG46-30*5	46	150	2950	37	162
D/DG46-50-7	46	350	2950	90	210
D/DG85-67*4	85	268	2950	110	235
D/DG85-67*8	85	536	2950	220	235
D/DG120-50*5	120	250	2950	132	213
D/DG150-30*8	150	240	2950	160	172
D/DG150-100*6	150	600	2950	400	289
D/DG200-100*6	200	600	2950	560	290
D/DG280-65*6	280	390	1480	500	430
D/DG360-40*8	360	320	1480	500	360
D/DG450-60*8	450	480	1480	900	430
D/DG550-50*9	550	450	1480	1000	430

For reference only, more details please contact us!

Pump will be tested before delivery:

Package:

Contact Us:
