Submersible Slurry Pump With Agitator

Name: Submersible Slurry Pump With Agitator Manufacturers and Factory China - Price List - DEPUMP
Brand: DEPUMP
SKU: 148647132

Submersible slurry pump is mainly used for cleaning and conveying of the slurry liquid of metallurgy, mine, iron and steel works, thermal power plant and other enterprises.

Product Details

Being a manager of metallurgy, mine, iron or steel works, thermal power plant or other enterprises, are you troubled with cleaning and conveying of the slurry liquid? If you are, you will absolutely find a way to solve your problem after reading this article.

Cleaning and conveying of the slurry liquid of metallurgy, mine, iron and steel works,themal power plant and other enterprises are mainly applications for submersible slurry pump with agitator. The liquid that submersible slurry pump conveys are sandstone, coal cinder, tailings and other solid particles, which means SS type slurry pump can handle different situations easily.

Depump's submersible slurry pump with agitator is always the best choice, there are seveal reasons as follow.

The advanced structure makes it suit for any different circumstances.
Wide flow channel enhance the flow capacity of the pump.
Strong discharge capacity makes our product better than other companies' products
The content of chrome is higher than 27%, which means a longer service time.

You can totally trust our products, which can bring you more profit for your enterprise. Depump always is your best choice.

Model	Outlet Dia. (mm)	Capacity (m³/h)	Head (m)	Power (Kw)	Speed (r/min)	Max.Dia.of Solid (mm)	Pump Weight (kg)
SS45-15-5.5	80	45	15	5.5	1460	13	100
SS15-20-5.5	80	15	20	5.5	1460	13	100
SS30-30-7.5	80	30	30	7.5	1460	13	114
SS50-26-11	80	50	26	11	1460	13	165
SS75-25-15	100	75	25	15	1460	13	220
SS150-18-18.5	150	150	18	18.5	980	32	550
SS200-12-22	150	200	15	22	980	45	580
SS60-46-30	150	60	46	30	980	21	700
SS150-30-30	150	150	30	30	980	21	550
SS300-20-37	200	300	20	37	980	28	775
SS200-30-45	150	200	30	45	980	36	1000
SS500-15-45	250	500	15	45	980	46	1100
SS250-35-55	150	250	35	55	980	36	1140
SS600-15-55	250	600	15	55	980	46	1140
SS350-35-75	200	350	35	75	980	28	1550
SS500-20-75	200	500	20	75	980	25	1550
SS200-60-90	150	200	60	90	980	14	1550
SS400-40-90	200	400	40	90	980	28	1550
SS600-30-110	200	600	30	110	980	28	1970
SS1000-18-110	300	1000	18	110	980	50	1970
SS500-45-132	200	500	45	132	980	28	2000
SS1000-22-132	300	1000	22	132	980	50	2000
SS650-52-160	200	650	52	160	980	28	2650
SS780-50-185	300	780	50	185	980	38	3330
SS800-55-220	300	800	55	220	980	38	3400
SS1250-35-220	350	1250	35	220	980	45	3400
SS1750-30-250	350	1750	30	250	980	55	3500
SS2000-35-315	400	2000	35	315	980	60	3700

Shirley S.

Phone/WA: +86 13932278621

Email: admin@deponpump.com

Website: www.deponpump.com

Materials:

NO.	Description	Standard Material	Material Options
1	Support Frame	Mild Steel
2	Strainer	420 Stainless Steel
3	Pump Casing	Cr27 White Iron	SS316, A49,CD4MCu
4	Back Plate	Cr27 White Iron	SS316, A49,CD4MCu
5	Impeller	Cr27 White Iron	SS316, A49,CD4MCu
6	Agitator	Cr27 White Iron	SS316, A49,CD4MCu
7	Oil Chamber Housing	Cast Iron
8	Shaft	420 Stainless Steel
9	Shaft Sleeve	420 Stainless Steel
10	Wet End Mechanical Seal	304 Stainless Steel
11	Motor Mechanical Seal	304 Stainless Steel
12	Motor Casing	Cast Iron
13	Motor Cooling Jacket	Fabricated Mild Steel
14	Lifting Brace	Mild Steel
15	Bearing Covers	Cast Iron
16	Oil Chamber Cover	Cast Iron
