Mining Rubber Lined And Marine Horizontal Centrifugal Slurry Pump
Product Details
Mining Rubber Lined and Marine Horizontal Centrifugal Slurry Pump
Basic Info
Max.Capacity: >400L/min
Impeller Number: Single-Stage Pump
Type of Impeller: Single Suction Pump
Pump Casing Combined: Vertical joint Surface Pump
Impeller: Closed
MOQ: 1 Set
Certificate: Ce
After Sales: Yes
Size: 1- 18 Inch
Head: 5 - 118m
Trademark: DE Or OEM
Specification: CE, SGS
HS Code: 8413709990
Max.Head: 80-110m
Driving Type: Motor
Working Pressure: High Pressure Pump
Position of Pump Shaft: Horizontal Pump
Mounting Height: Suction Centrifugal
Usage: Pump, Pumps, Condensate Pump, Ash Pumps, Circulating Pump, Slurry Pump
OEM: Accept
Pump Type: Centrifugal Slurry Pump
Color: As customers request
Capacity: to 5400 M3/H
Material: High Chrome Alloy or Rubber
Transport Package: Packed with Wooden Box or as Customer′s Request
Origin: Baoding, China
Performance Curve
Pump Structure
MAH SLURRY PUMP PERFORMANCE PARAMETERS
Type | Allowable Mating Max. Power(Kw) | Clear Water Performance | Impeller | |||||
Capacity/Q m3/hr | Head/m | Speed/rpm | Max Efficiency/% | NPSH/m | Nos of Vane | Impeller Diameter/mm | ||
1.5X1-MAH | 15 | 12.6--28.8 | 6--68 | 1200--3800 | 40 | 2--4 | 5 | 152 |
2X1.5-MAH | 15 | 32.4--72 | 6--58 | 1200--3200 | 45 | 3.5--8 | 5 | 184 |
3X2-MAH | 30 | 39.6--86.4 | 12--64 | 1300--2700 | 55 | 4--6 | 5 | 214 |
4X3-MAH | 30 | 86.4--198 | 9--52 | 1000--2200 | 71 | 4--6 | 5 | 245 |
6X4-MAH | 60 | 162--360 | 12--56 | 800--1550 | 65 | 5--8 | 5 | 365 |
8X6-MAH | 300 | 360--828 | 10--61 | 500--1140 | 72 | 2--9 | 5 | 510 |
10X8-MAH | 560 | 612--1368 | 11--61 | 400--850 | 71 | 4--10 | 5 | 686 |
12X10-MAH | 560 | 936--1980 | 7--68 | 300--800 | 82 | 6 | 5 | 762 |
14X12-MAH | 560 | 1260--2772 | 13--63 | 300--600 | 77 | 3--10 | 5 | 965 |
16X14-MAH | 1200 | 1368--3060 | 11--63 | 250--550 | 79 | 4--10 | 5 | 1067 |
18X16-MAH | 1200 | 2520--5400 | 13--57 | 200--400 | 85 | 5--10 | 5 | 1370 |
Feature
· Bearing assembly- large diameter shaft with short overhang contributes to long bearing life.
· Liners – easily replaceable liners are bolted, not glued to the casing for positive maintenance.
· Casing – Casing halves of cast or ductile iron provide high operating pressure capabilities.
· Impeller – front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.
· Throat bush – wear is reduced and maintenance simplified by the use of tapered.
Welcome to contact me for more details.
