75kw WQ Submersible Sewage Water Pump
Product Details
TheDEPUMP®WQ Series submersible sewage pump is mainly used for municipal works, industrial buildings,hotels,hospitals,civil air defense,mines etc. Trades to drain off the sewage, waste water, rainwater and living water in cities containing solid grains and various long fabrics.
<img
Features
1 High stength cast iron pump construction;
2 Impeller options are available to suit a range of applications and pumped products including single,double or triple vane;
3 420 stainless steel shaft;
4 Built in cooling system allows operation when motor is submerged or above water level.
Model Meaning
Structure Of Pump
Performance Curve
Performance Table
Type | Outlet Dia. (mm) | Capacity (m3/h) | Head (m) | Power (kw) | Efficiency (%) |
50WQ15-8-0.75 | 50 | 15 | 12 | 0.75 | 52 |
65WQ30-10-2.2 | 65 | 30 | 10 | 2.2 | 62 |
80WQ50-8-2.2 | 80 | 50 | 8 | 2.2 | 60 F |
100WQ80-7-3 | 100 | 80 | 7 | 3 | 64 |
150WQ150-10-7.5 | 150 | 150 | 10 | 7.5 | 72 |
200WQ300-10-15 | 200 | 300 | 10 | 15 | 74 |
250WQ500-10-30 | 250 | 500 | 10 | 30 | 72 |
300WQ700-19-55 | 300 | 700 | 19 | 55 | 75 |
350WQ1100-25-110 | 350 | 1100 | 25 | 110 | 76 |
400WQ2000-23-185 | 400 | 2000 | 23 | 185 | 80 |
500WQ3000-15-132 | 500 | 3000 | 15 | 185 | 72 |
*****More pump models please contact us*****
