Electric Centrifugal Horizontal Stainless Steel Chemical Pump With Explosion Proof Motor OEM Manufucture

Range of Performance *Capacity: 6.3-400m3/h *Head: 5-125m *Speed: 2900r/min and 1450r/min *Power of fitted motor: 0.55-90kw *Inlet diameter: 50-200mm *The max. working pressure: 1.6Mpa

Product Details

IH Type Pump Performance
Type	Capacity(m3/h)	Head(m)	Speed(r/min)	Motor Power(kw)	Eff.(%)	NPSH(m)
IH50-32-125	7.5-15	18-23	2900	2.2	51	2
IH50-32-125	3.75-7.5	4.5-5.75	1450	0.55	45	2
IH65-50-125	15-30	18.6-21.3	2900	3	62	2
IH65-50-125	7.5-15	4.5-5.4	1450	0.55	55	2
IH65-40-315	15-30	124-136.8	2900	30	39	2
IH65-40-315	7.5-15	31.7-32.4	1450	5.5	33	2
IH80-65-160	30-60	28.4-36	2900	11	67	2
IH80-65-160	15-30	7.2-9	1450	1.5	62	2
IH100-65-200	60-120	44-56	2900	22	72	3.9
IH100-65-200	30-60	11-14	1450	3	68	2.5
IH125-100-250	120-240	73-90	2900	75	75	4.5
IH125-100-250	60-120	18.25-22.5	1450	11	72	2.3
IH150-125-315	120-240	28.5-36.3	1450	30	75	2.8
IH150-125-400	120-240	44-57.5	1450	55	70	2.5
IH200-150-315	240-460	29.4-35.6	1450	55	79	3.5
IH200-150-400	240-460	47-55.8	1450	90	78	3.5

Range of Performance

*Capacity: 6.3-400m3/h
*Head: 5-125m
*Speed: 2900r/min and 1450r/min
*Power of fitted motor: 0.55-90kw
*Inlet diameter: 50-200mm
*The max. working pressure: 1.6Mpa
